Hi there,
I’m thinking about what kind of opportunities there is for a portable media center you can have with you in the car, train or whatever.
I imagine that the media center would create its own WiFi, so that devices would be able to connect to it and access the media.
I know you could do something with a Raspberry Pi, but how could this work in practice? What would be an easy way to access the media from an iPad fx? What software could be used?
As a bonus, it would be pretty cool if the media center could connect to a hotel WiFi and then create a hotspot from that.
Edit: This would be used when on the move. So you would have the media with you on the media center.
You don’t need anything as elaborate as you appear to be contemplating.
Insert a large capacity microSD card into your mobile phone and load it up with media.
Share as required.
I use iPhone and the kids have iPads, but let’s say I had a phone with expandable storage. How would I share the content from the phone to the iPads?
How much storage do they have these days? Personally I’d just load a bunch of media directly on to the devices and not worry about additional hardware or networks.
The iPads only have 64GB and I do usually download some stuff from Netflix, ATV+ and Plex if it actually worked.
My Plex server runs in my home and all my media is available outside my home. A travel server seems like a solution for a problem that doesn’t really exist.
If you are on the road or simply travelling a place with bad internet, then what?
You read, you walk, you get to see places…
Genius! Why didn’t I think of that 😂
When I know I’m travelling, I always download a few select movies and the next few episodes of whatever we’re currently watching to my devices.
Plex allows me to download using my PlexPass. My family/everyone else that uses my server download the media they want via my JellyFin server (serving the same media as my Plex server).
I use Plex’s download feature to make sure I always have music available. The same could be done for other media but I don’t bother.
At least in the case of a Jellyfin server, you can download media locally when you know you’ll be without internet
True, but if your devices, in this case; iPads with only 64GB, it quickly gets filled up.
Not sure if this helps, but e-sims are extremely cheap and can be set up on the go through an app these days. You could get a 5g plan in the area with bad internet and use it as a hotspot to download content to your other devices. I use Nomad, but there are a lot of providers with plans that are unlimited or pay by the gig—all affordable with time periods as short as 7 days.
A $10 solution, in a pinch, is a good choice.
It’s not a bad solution and I have used eSIMs before when I was traveling in Asia. However, all of these “unlimited” eSIM plans has a lot of buts. Either the speed is limited to close to unusable for streaming and/or you are limited to only use x amount of GB when using hotspot.
Also depending on the country, the coverage can be awful.
If you’re carrying your media with you, you could run Jellyfin on the server to provide access to the media to anyone connected to its wifi.
Exactly. The point is to carry the media with you and access it without an actual internet connection. Especially on the go.
If I understand you correctly, I could install Jellyfin on a Raspberry Pi, setup a local WiFi on it and connect to it with an iPad that has a Jellyfin client installed?
and connect to it with an iPad that has a Jellyfin client installed?
In my experience, you don’t even need the dedicated Jellyfin client. Just opening it up in a web browser works out of the box, so that’s potentially one less thing to download/install/manage for the clients.
That said, I’ve never tried to access Jellyfin from an iPad/iPhone/Mac so it might not be as seamless as my experiences on Android/Linux based devices. But I imagine they’d be fine; just test it out before you hit the road.
Generally the app is better. Compatible with more container formats, audio formats (surround sound, Dolby digital, etc), and has hardware supported decoding for h265 video in addition to h264.
Yes, I’ve done almost exactly this while traveling. You can even carry around a couple variously configured sd cards for different use cases. I had one with jellyfin for sharing locally and also Kodi for direct HDMI connection to TVs. There is a in app on Android for jellyfin called findroid that allows offline copies from the media server, which allowed me to not need the thing powered the entire time I wanted to watch something on my phone, just long enough to download it. Adding samba shares adds a other layer of accessibility. I had another SD Card with video game ROMs for retro gaming, but this one got left at home because it requires controllers and I didn’t think I’d use it that much. I had another with “little backup box” installed for automatically backing up my photos and videos after a day out exploring with my camera.
I used a Raspberry pi 5 for all of this, running from a battery backup, because I didn’t really need a keyboard once I had remote connections to my phone sorted out. Pick a rugged case and you case just toss it in your bag of chargers. It took up about as much space as a pack of cigarettes. Another option would be the Raspberry Pi 400, built into a keyboard. A little bulkier, but maybe more resilient in the face of technical difficulties.
Yup. If the sd card doesnt have enough space for everything, you could attach an m.2 hat to it as well. https://www.raspberrypi.com/news/using-m-2-hat-with-raspberry-pi-5/
Basically, jellyfin on the pi, with the wifi setup as an access point, and whatever amount of storage you need. The pi requires 5v/5a, so you’ll probably run into issues running off the car usb power, but a cheap 30amp hour battery should run it for 6-10 hours if my napkin math is right.
You don’t need a special client, just a browser. Otherwise, yep!
While I agree with others pointing out the oddity of a portable server in general: this sounds like a great use-case for a laptop.
Built-in battery, wifi you can broadcast out as a hotspot, and it even has a display/keyboard/mouse for troubleshooting!
An older laptop with the optical drive stripped out could have a 2.5” 5TB HDD in addition to the boot drive for some decent mobile storage.
Feels like a convoluted way of using an external hard drive.
Can you connect the hard drive to multiple devices? 😉
Probably an rpi and a travel router. But seems like the best setup would be a media server you kept at home and a VPN to connect to it from anywhere.
Why would you need a travel router?
The rpi already can be set up to hotspot it’s own wifi network.
For connecting to hotel wifi, a simple usb dongle is good enough, as discussed here: https://forums.raspberrypi.com/viewtopic.php?t=287485
In regards to VPN-ing into the media server at home - depending on where you travel, you might not have any internet or you might use up your mobile data volume.
I used a raspberry pi 3 with RaspAP in this use case in my room at home for some time. Performance was not the best, but enough for my needs back then.
Yeah you can use the rpi as the router too
Exactly and thank you for the link! 😁
I am looking for a solution where you have the media with you, so you don’t need an internet connection to watch your media.
The media server at home is a great solution that I already use, but if you have 3 people watching in the car, using mobile data, you won’t have anything left when you get to your destination😅
Pi5 may be a good solution then. Might also try a radxa x4. It has wifi 6 so more bandwidth for multiple wifi clients. Plus an m.2 slot. Only thing that sucks is there’s like no cases for it.
I carry a mini PC, Bluetooth remote, and HDMI cable. Then media and automatic VPN to home as every hotel and Airbnb blocks Plex.
It’s a good setup, but I don’t think this would work in a car and using iPads.
I’m running Navidrome on my Raspberry pi (4). On my phone (Pixel 8) I use Symfonium to connect with Navidrome. When I’m travelling I use Tailscale + Mullvad + Symfonium to play music from my rpi.
Fuck it, throw a 512 GB SD in an old phone and run a full jellyfin server in termux
I will definitely try this out! 😁
Can’t say ive don’t the full thing myself cause I couldnt find an easy way to mount network drives (there was a lot of jerry-rigging going on), but ive gotten to a webui before
Search for portable Jellyfin media server projects. It looks like there’s a few out there.
If you’re going to use this in a car, it needs to be as simple as plugging in a single device and powering it on. An over-engineered solution is going to quickly turn into a headache.
You can install Plex on your mobile device and toggle the “share media from this device” setting. Otherwise, a steam deck would have everything an RPI has plus a GPU and a touch screen. Since there are two radios (2 and 5Ghz) on the device, you should be able to set it up as a bridge device, but I’ve not tried this personally.
Travel router and VPN.
What if I have no internet? 😅
deleted by creator
I did this a few years ago with a stack of pi 4s connected to a four port PoE switch. One was an openWRT router, one was a plex server connected to some spinning discs via usb, and I had another you could plug an hdmi cable into and use to view the media. I eventually found out I could host the whole thing on a single pi, but it was still a fun project. Could probably do it all on a pi 5 with an nvme hat no problem. Might look into that when I get the spare tinkering money.
An ancient cheap small laptop would do it fine. Plex or Jellyfin software
